Maximize your kitchen’s output in half the footprint! The TurboChef HhC 2020 Double-Stack is the gold standard for high-volume pizzerias, cafes, and commercial kitchens. Utilizing advanced top and bottom impingement airflow, it cooks pizzas, paninis, and wings up to 50% faster than conventional conveyor ovens with perfect consistency. Featuring two fully independent modules, you can run separate temperatures, belt speeds, and menus simultaneously.

✨ Key Features
Independent Dual Modules: Operate top and bottom ovens with entirely separate recipes, times, and temperatures.
Advanced Impingement Technology: Independently controlled top and bottom air crunch streams for perfectly crisp results.
Smart Digital Controls: Integrated VFD displays capable of storing up to 8 custom cooking profiles/recipes per oven.
Reversible Belt Direction: Conveyor belt direction is electronically configurable (Left-to-Right or Right-to-Left).
Premium Construction: All-stainless steel exterior and interior design built for heavy-duty commercial use and easy cleaning.
Energy-Saving Idle Mode: Dramatically reduces power consumption during slow kitchen hours.

📐 Dimensions
Total Height (With Mobile Caster Base): 60.1 inches (1527 mm)
Total Width (Conveyor Belt Length): 48.3 inches (1227 mm)
Total Depth (Oven Body): 35.7 inches (907 mm)
Baking Chamber / Belt Width: 20.0 inches (508 mm)

⚡ Electrical Specifications (Per Oven Module)
Note: Requires two separate/independent electrical drops at your breaker panel.
Voltage: 208 / 240 V AC
Phase: 3 Phase (Trifásico)
Frequency: 50/60 Hz
Amperage (Per Module): 40 A (at 208V) / 46 A (at 240V)
Max Input Power (Per Module): 14.4 kW (at 208V) / 19.0 kW (at 240V)
Combined Total Power (Both ovens at 240V): 38.0 kW

🆔 Factory Identification & Serial Numbers
Consecutive, original factory sister units ensuring they have been operated together under identical kitchen conditions:

Serial Number: HhC 2020ED09322
Serial Number: HhC 2020ED09323
Manufacture Date: January 2020 (JANUARY-2020)
Manufacture Code: TC-01

⚙️Condition: Used / Fully Tested

📸 Be sure to review all images for condition
